Create the clean and medium overdrive tones like the ones you hear in music from Lowell George and David Lindley. This amplifier’s voice is rooted in the Fender Blackface and Tweed tone, with an upfront and raw voice, infused with a singing quality.
The Welagen Overdrive Special is simply the ultimate small dynamic lead amp with excellent projection and tonal balance. It has both Clean and Overdrive channels. The EQ controls and switches provide a variety of tones. The tube buffered effects loop allows for seamless integration of outboard effects.
Matching speaker cabinet available upon request.
GENERAL SPECS
- Power output: 50 or 100 Watt
- Power consumption: 120 or 240VAC, 50/60 Hertz
- Output impedance: 4, 8, 16 Ohms
- Input impedance: NOR = 1M Ohm, and FET = 3.3M Ohms
TUBE COMPLIMENT
- 4 x 7025 high-mu twin triodes
- 2 or 4 x 6L6-GC beam power tubes
CONTROLS AND EQ SWITCHES
- Preamp controls: Volume, Treble, Middle, and Bass
- Preamp switches: Bright, Deep, Rock/Jazz
- Overdrive controls: Level, Volume
- Overdrive switch: manual/pedal select
- JWater effects loop: Send level, Return Level, JWATER/Bypass select
- Master section: Master Volume, and Presence
SIGNAL CONNECTIONS
- Inputs: NOR, and FET
- Access ports (effects loop): Preamp Out/Send, Power Amp, Input/Return, Loop/Bypass Select
- Outputs: Main Speaker, Extension Speaker
POWER SWITCHES
- A.C. mains on/off
- Operate/Standby
- 100/50 Watt Output Select (4-powertube versions only)
REMOTE SWITCHING
- Overdrive on/off
- Special design footswitch
