Create tones like you hear in music from Robben Ford, 80s Larry Carlton, and Santana with the 80s Overdrive Special. This amplifier will provide you with tones ranging from cleans with percussive crystal clear tones to a wonderful touch sensitive overdrive and compression.
The Welagen Overdrive Special is simply the ultimate small dynamic lead amp with excellent projection and tonal balance. It has both Clean and Overdrive channels. The EQ controls and switches provide a variety of tones. The tube buffered effects loop allows for seamless integration of outboard effects.
Matching speaker cabinet available upon request.
GENERAL SPECS
- Power output: 50 or 100 Watt
- Power consumption: 120 or 240VAC, 50/60 Hertz
- Output impedance: 4, 8, 16 Ohms
- Input impedance: NOR = 1M Ohm, and FET = 3.3M Ohms
TUBE COMPLIMENT
- 4 x 7025 high-mu twin triodes
- 2 or 4 x 6L6-GC beam power tubes
CONTROLS AND EQ SWITCHES
- Preamp controls: Volume, Treble, Middle, and Bass
- Preamp switches: Bright, MID, Rock/Jazz
- Preamp boost (PAB): manual/pedal select (optional)
- Overdrive controls: Level, Volume
- Overdrive switch: manual/pedal select
- JWater effects loop: Send level, Return Level, JWATER/Bypass select
- Master section: Master Volume, and Presence
SIGNAL CONNECTIONS
- Inputs: NOR, and FET
- Access ports (effects loop): Preamp Out/Send, Power Amp, Input/Return, Loop/Bypass Select
- Outputs: Main Speaker, Extension Speaker
POWER SWITCHES
- A.C. mains on/off
- Operate/Standby
- 100/50 Watt Output Select (4-powertube versions only)
REMOTE SWITCHING
- Preamp boost on/off
- Overdrive on/off
- Special design footswitch
